0.9mm LC Type Fiber Optic Connectors Single Mode SC / FC / LC / ST / E2000

Name: 09mm LC Type Fiber Optic Connectors Single Mode SC FC LC ST E2000
Brand: New Light
Price: 0.1 USD

Buy cheap 0.9mm LC Type Fiber Optic Connectors Single Mode SC / FC / LC / ST / E2000 product

Brand Name : New Light

Model Number : ST

Certification : CE / ISO / RoHS

Place of Origin : China

MOQ : 100

Price : 0.1~100

Payment Terms : T/T, Western Union, MoneyGram, paypal

Supply Ability : 10,000 pcs per month

Delivery Time : 7 working days

Packaging Details : standard export package

material : metal

mode type : single mode / multi mode

connector type : 3.0mm

Insertion loss : <0.3dB

certificate : CE , ISO , RoHS

return loss : PC≥40 UPC≥50 APC≥60 dB

Contact Now

0.9mm single mode SC / FC / LC / ST / E2000 lc type fiber optic connector

Field-mountable optical fiber connectors are used to join optical fiber jumper cables that contain one single-mode fiber. Field-mountable optical fiber connectors are used for field restoration work and to eliminate the need to stock jumper cords of various sizes.
These assemblies can be separated into two major categories: single-jointed connector assemblies and multiple-jointed connector assemblies. According to Telcordia GR-1081,[17] a single-jointed connector assembly is a connector assembly where there is only one spot where two different fibers are joined together. This is the situation generally found when connector assemblies are made from factory-assembled optical fiber connector plugs. A multiple-jointed connector assembly is a connector assembly where there is more than one closely spaced connection joining different fibers together. An example of a multiple-jointed connector assembly is a connector assembly that uses the stub-fiber type of connector plug.

Attributes

High return loss (low amounts of reflection at the interface)
Ease of installation
Low cost
Reliability
Low environmental sensitivity
Ease of use

0.9mm LC Type Fiber Optic Connectors Single Mode SC / FC / LC / ST / E2000

Features:

---Low insertion loss and back reflection loss
---Ferrule end surface pre-domed
---Precision anti-rotation key
---Nickel plated brass body
---Telcordia style boots
---Free-floating ceramic ferrule

Parameter

products name	OEM / ODM 3.0mm Fiber Optic ST Connector For Indoor Distribution Patch Cord
mode type	single mode / multi mode
cable diameter	3.0 mm
insertion loss	≤ 0.3dB ( low insertion loss can be ≤ 0.35dB )
return loss	≥60 dB
wave length	1310/1550
ferrule material	Ceramic
operater temperature	-40~ +85℃
OEM/ODM	acceptable
warranty	3 years after delivery
Delivery time	2-15 working days ( according to your quantity )

more connector for reference

0.9mm LC Type Fiber Optic Connectors Single Mode SC / FC / LC / ST / E2000

Connector type	LC / SC / FC / FC / E2000 / MPO /MTRJ /SMA
Mode type	single mode or multimode
Cable type	0.9 / 2.0 / 3.0 mm

How to order

1. Connector type : SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
2. Mode type : single mode ( UPC and APC ) / multi mode ( PC )
3. Cable diameter : 0.9 / 2.0 / 3.0 mm ( can customized other diameter )
4. Coating material : PVC / LSZH
5. fiber count : simple / duplex / 4 core / 6core / 8 core /12 core / 24core/48 core / 96 core and so on
6. Cable type : G652D / G657A1 / G657A2 /G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 /OM5
7. Patch cord length : according to your requirement
8.MPO/MTP connector should let us know which method ( A type / B type /C type ), male or female , fiber count (4/8/12/16/24/32 fiber )

Product Tags:

fiber optic cable connectors

fiber optic fast connector

0.9mm LC Type Fiber Optic Connectors Single Mode SC / FC / LC / ST / E2000 Images
